Volumetric pumps with type V elliptical piston

V 10 | V 15 | V 18 | V 20

The V series pumps are one of the most successful MORI innovations over the decades.

This equipment can boast a series of improvements and an evolutionary path of rare significance.

Suitable for transporting semi-solid materials such as whole or destemmed grapes and fermented grape marc.

All equipped with a tilting hopper in order to proceed with the racking of tanks whose door height is lower than that of the loading hopper (ESLUSO V. 20).

Transmission is by means of a robust gear motor at low revolutions, guaranteeing a service factor that makes the motor-reducer unit extremely long-lasting.

The speed of rotation of the nosepiece is reduced to a minimum to ensure less stressful treatment of the raw material: 70 RPM.

Complete with motor protector on all models and inverter on models V.15-18-20.

They can be fitted with plastic inserts on the ogive for transporting grapes and marc from mechanical harvesting, thus reducing blockages and damage caused by ferrous foreign bodies to a minimum.

Electrical panel on board the machine in compliance with EC standards.
